iNFiNiT! Family Operation Manual
Revision D 2-49 Installation
For example, if the status line on the Prompts Monitor shows
Message 0089 already exists
, the display would appear
as follows:
Figure 2-23. Keyboard LCD
Immediately after the operating system is loaded, the LCD dis-
play shows
SYSTEM READY
until an application program is
loaded.
$ERXW0DFKLQH&RQWURO2SWLRQ''5
Machine Control allows an iNFiNiT! Family system to control
a Digital Disk Recorder (DDR) for playback in Multiple Effects
(Section 17) Multiple Effects and IMAGESTOR! applications.
Special hardware and software configuration as described
below must be performed to use this option. The Machine Con-
trol Option program (
/SYSTEM/PROGRAMS/DDR.OPT
) is
required for DDR support in both Message Compose and
IMAGESTOR!.
''56HWXSL1)L1L7
WARNING!
Serial Port 2 on the iNFiNiT! is dedicated
to the DDR, and
must
be reconfigured
from RS-232 to RS-422
before
the DDR is
connected. This involves changing a
jumper on the CPU Transition Board.
Failure to perform the reconfiguration can
result in equipment damage!
Please refer
to the Machine Control Option Handbook
(Pub. No. 2A01918) for more information.
The Machine Control Option program (
/SYSTEM/PRO-
GRAMS/DDR.OPT
) is required for DDR support in both
Message Compose and IMAGESTOR!.
Message exists.
0089
