iNFiNiT! Family Operation Manual
Revision D 2-19 Installation
*HQHUDO3XUSRVH,QWHUIDFH
*3,+RRNXS
The GPI Interface is used to trigger function-key sequences (of
up to 500 keystrokes each) via external switch closures. Func-
tion Key setup and operation is provided in Section 12 of this
manual.
The normally open single-pole GPI switches shown in the dia-
grams are not included with the system. Any type of momentary
switching device may be used, but switch contact bounce time
must be 20 ms or less.
This section is divided into separate parts due to differences in
the iNFiNiT! Family hardware configuration.
L1)L1L7*3,+RRNXS
The GPI connector on the iNFiNiT! CPU Transition Board can
be used to activate Function Keys
F1
through
F8
.
RED
If RGB/YUV equipped, supplies the red or V component
from the RGB/YUV board. (0.7v p-p)
REF IN
External (house) genlock input, if MAXINE! internal
genlock is not to be used. (1.0v p-p)
Table 2-6: MAXINE! Video Connections
&RQQHFWR U 'HVFULSWLRQ
