iNFiNiT! Family Operation Manual
Revision D 2-37 Installation
NOTE
The S1 switch should only be changed
while the MAXINE! unit is powered off.
$QDORJ'LJLWDO6\QF*HQHUDWRU
'LIIHUH QFHV0$ ;,1(
For analog-equipped units configured for PAL (625 line), the
internal sync generator does not include the 25 Hz offset cir-
cuitry; therefore, connection to an external reference is recom-
mended. For digital-equipped units, the COLOR EDIT output
includes the 25 Hz offset circuitry.
For analog-equipped units, the internal sync generator provides
both a line lock to the horizontal sync pulses and a color lock to
the color burst, if present on the REF IN. For digital-equipped
units, the sync generator only provides a line lock since there is
no color burst present on the 601 outputs; the COLOR EDIT
output is factory set to have 0 ScH phase in both genlock and
stand alone modes.
For Digital Input-equipped units, the sync generator can be set
to genlock to the 601 VID IN signal.
The analog-equipped unit must have the external reference con-
nected while the MAXINE! is OFF (or else the system must be
rebooted). The digital-equipped unit does not have this restric-
tion.
S1 - 3
Always ON
S1 - 4
Keyer Enabled (Digital Out-
put equipped systems only)
Keyer Enabled (Digital Input
equipped systems only
Color Edit Gain:
Adjusts overall amplitude of the Color Edit output.
VCO Adjust:
Adjusts the free running frequency of the voltage con-
trolled oscillator for the sync generator in stand alone
mode (not genlocked).
Table 2-12: MAXINE!
Sync Gen Digital Video Board Adjustments
6ZLWFK 2Q 2II
