CHYRON Corporation
Advanced Read FX 15-44 Revision D
)*(IIHFW)RUHJURXQG(IIHFW
FG Effect gives the ability to execute Read Effects of an
Output Percentage between
0 and 100 over a static image
(text or RGB(A) image) or no image. The static image is
read into the background buffer of the EEFB. Read
Effects is performed as usual. Both Foreground and
Background buffers can be set to Output Percentages
between
0 and 100.
When FG Effect is activated, all buffers are affected.
The following Effect Types can be executed in using FG
Effect: Wipes (§15.5.1) and Pushes (§15.5.2).
Rev
(Reverse - §15.3.2) and
Ease (§15.3.3) can be set for
each of these Effect Types.
Figure 15-14. Wipe and Push
Transition Patterns A and B (§15.5) are available to Wipe
and Push for this feature.
Figure 15-15. Transition Patterns A and B
Wipe
Push
B
A
