Mix Effects 16-4 Revision D
 (IIHFW7\SHV
An Effect Type governs how an old image leaves the
screen and the new image enters the screen. There are
two Effect Types:
Wipe and Fade. The default setting is
Wipe. To select an Effect Type:
• Place the cursor over the desired Effect Type, then
press

or SPACE BAR, or select using the mouse.
Wipe As Wipe (§16.6.3) executes, the new image overwrites
the old image. Neither image moves. All Transition Pat-
terns
A - D are available to Wipe.
Fade A Fade (§16.6.1) is a full screen transition. An image in
one frame buffer is faded out as an image from another
frame buffer fades in.
 (IIHFW3DUDPHWHUV
 6SHHG
The speed (duration), edge softness, direction, and ease
of the effects can be changed.
Soft
Soft
(§16.5.2) specifies the width (in pixels) of the
edges that separate the image in one buffer from the
image in another buffer. Soft
is available only to Wipe
and Soft Mask. Soft can be set from 1 (hard edge) to
60 (soft edge). (Default soft setting is 20)
Reverse
Reverse
(§16.5.3) indicates the direction of the transition.
Can be
On or Off. The default setting is Off.
Ease
Ease
(§16.5.4) indicates whether or not the transition accel-
erates to set speed and/or decelerates from set speed or
runs at a constant (set) speed.
Ease can be set to In, Out,
In/Out, or None (Default).
