CHYRON Corporation
Advanced Playback 9-58 Revision D
5HFRUG&UDZO&RQWURO %XIIHU/LVW
To record the Crawl Control Buffer List:
• From the Message Compose main menu, press
CLR, enter an empty address on the Address
Keypad, then press
CNTL RCD CRAWL.
6SOLW5RZ&UDZO
It is possible to set up to crawl a row or rows at the top of
the screen, and a row or rows at the bottom of the screen,
while displaying a static image in between. For example,
to display one crawling row at the top of the screen, and
one at the bottom of the screen:
[ ] 1. Enter text on the top three rows (rows 0, 1, and 2).
Figure 9-14. Split Row Crawl Setup Step 1
[ ] 2. In the Unlocked Mode (§6.4.1), use the SHIFT
ROW
function to move Row 1 below Row 2.
You can also adjust the position of Row 2 if
necessary.
Figure 9-15. Split Row Crawl Setup Step 2
[ ] 3. Record the page as a Full Page message.
Row 0
Row 1
Row 2
Row 0
Row 1
Row 2
