CHYRON Corporation
Installation 2-18 Revision D
 9LGHR&RQQHFWLRQV0$;,1(
EXT SCSI
The Small Computer System Interface (SCSI) is the I/O
port for the internal hard drive. A SCSI Terminator, or
external disk storage unit(s) attach to this connector.
If
no external drive units are connected, the sup-
plied SCSI terminator must be installed here for
proper hard disk operation!
GPI
General Purpose Interface. Allows you to use remote
switches to activate Function Keys
F1
through
F8
.
ETHERNET
Network connection for use with Network Utilities soft-
ware (optional).
Table 2-6: MAXINE! Video Connections
&RQQHFWRU 'HVFULSWLRQ
VIDEO OUT 1
Composite video output, consists of MAXINE! text,
graphics, effects, and/or backgrounds. Does not include
Safe Title Box, cursor, or tab fields. (1.0v p-p)
COLOR EDIT
Same as VIDEO OUT 1, plus displays Safe Title Box,
cursor, and tab fields. (1.0v p-p)
PROMPTS
Displays icon based prompts, menus, commands and cur-
rent operating information such as mode, color and font
specifications. Connect this output to a monochrome
monitor. Only one prompt output is available on MAX-
INE! (Monochrome)
KEY OUT
Provides an analog (linear) key output. (1.0v p-p)
SYNC
If component output (RGB) is used, this jack supplies a
sync output. (4.0 v p-p NTSC; 2.0 v p-p PAL)
BLUE
If RGB/YUV equipped, this supplies the blue or U com-
ponent from the RGB/YUV board. (0.7v p-p)
GREEN
If RGB/YUV equipped, this supplies the green or Y com-
ponent, and sync (if desired), from the RGB/YUV board.
(0.7v p-p)
Table 2-5: MAXINE! Rear Panel Connections
&RQQHFWRU 'HVFULSWLRQ
