iNFiNiT! Family Operation Manual
Revision D 2-15 Installation
 9LGHR&RQQHFWLRQV0$;!
The two sets of BNC connectors on the MAX!> rear panel
(marked CHANNEL 1 and CHANNEL 2) are completely inde-
pendent. Except where noted, the following descriptions apply
to both channels (second channel optional).
EXT SCSI
The Small Computer System Interface (SCSI) is the I/O
port for the internal hard drive. A SCSI Terminator, or
external disk storage unit(s) attach to this connector.
If
no external drive units are connected, the sup-
plied SCSI terminator must be installed here for
proper hard disk operation!
GPI
General Purpose Interface. Allows you to use remote
switches to activate Function Keys
F1
through
F8
.
ETHERNET
Optional. Network connection for use with Network Util-
ities software.
Table 2-4: MAX!> Video Connections
&R QQHFWRU 'HVFULSWLRQ
CHYRON VIDEO
Output consists of MAX!> text, graphics, effects,
and/or backgrounds. Does not include Safe Title
Box, cursor, or tab fields. (1.0v p-p)
COLOR EDIT
Same as CHYRON VIDEO, plus displays Safe Title
Box, cursor, and tab fields. (1.0v p-p)
SYNC
If component output (RGB) is used, this jack sup-
plies black burst to the SYNC IN jack of your equip-
ment. (4.0 v p-p NTSC; 2.0 v p-p PAL)
BLUE
If RGB/YUV equipped, this supplies the blue or U
component from the RGB/YUV board. (0.7v p-p)
GREEN
If RGB/YUV equipped, this supplies the green or Y
component, and sync (if desired), from the RGB/
YUV board. (0.7v p-p)
Table 2-3: MAX!> Rear Panel Connections
&RQQHFWR U 'HVFULSWLRQ
