iNFiNiT! Family Operation Manual
Revision D 2-7 Installation
Figure 2-3. MAXINE! Chassis, Keyboard/Mouse Ports
Figure 2-4. Keyboard Rear Panel (MAXINE!)
1
0
INTEL INTF TABLET KEYBOARD
MOUSE P2
+5 +12 -12 GND
ETHE
To MAXINE! Keyboard
To Mouse
optional
1
0
Power Switch
KEYBOARD IN
KEYBOARD OUT
SEE BOTTOM FOR RATING LABEL
FUSE
3A SLO BLO
100 - 240 VAC
To next ke
board
To MAXINE! Chassis
