CHYRON Corporation
Advanced Playback 9-30 Revision D
The following table demonstrates how to set up Roll exe-
cutions for some of the above operations.
5ROO7\SHDQG
%DFNJU RXQG
1RDQG7\SH
RI%XIIHUV
%XIIHU$VVLJQPHQWV
Standard Roll
RGB(A) or Live
Background
2 standard [ ] 1. Press
MIX to enter the Mix Control
window (§16.3). In the Mix Settings
window (§16.7), assign one buffer to
Channel A and the remaining buffer
to Channel B.
[ ] 2. Either press
CNTL I to enable
Video Input, or read an RGB
Message ID number into Channel B
[ ] 3. Exit Mix Control, then execute Roll.
Standard Roll
RGB(A)
Background
1 EEFB/CCFB [ ] 1. Press
CNTL R to enter Read
Effects main menu.
[ ] 2. Select
Background as the active
buffer, then set background level.
[ ] 3. Read RGB(A) message into
background buffer.
[ ] 4. Exit Read Effects, then execute
Roll.
Standard Roll
Live
Background
1 EEFB/CCFB [ ] 1. Press
CNTL R to enter Read
Effects main menu.
[ ] 2. Press
CNTL V.
[ ] 3. Exit Read Effects, then execute
Roll.
