iNFiNiT! Family Operation Manual
Revision D 9-31 Advanced Playback
Special Roll
None or
Scanline
Background
2 standard [ ] 1. Press MIX to enter the Mix Control
window (§16.3). In the Mix Settings
window (§16.7), assign one buffer to
Channel A and the remaining buffer
to Channel B.
[ ] 2. Read a Scanline Background into
Channel B.
[ ] 3. Exit Mix Control, then execute
Special Roll.
1 EEFB/CCFB • Set up Roll Control Buffer List, then
execute Special Roll.
Special Roll
RGB(A)
Background
3 standard [ ] 1. Press
MIX to enter the Mix Control
window (§16.3). In the Mix Settings
window (§16.7), assign one buffer to
Channel A and a second buffer to
Channel B.
These two channels are then
dedicated to the Special Roll.
[ ] 2. Press
CNTL B.
This changes the Preview
assignment display to a background
assignment display (
Bkg Select -
§16.11).
[ ] 3. Assign the remaining buffer that will
contain the RGB(A) image to the
background channel, then exit Mix
Control.
This mixes the background channel
with Channels A and B for output.
[ ] 4. Read the RGB(A) image into the
background or Preview channel.
[ ] 5. Execute Special Roll.
5ROO 7\SH DQG
%DFNJURXQG
1RDQG7\SH
RI%XIIHUV
%XIIHU$VVLJQPHQWV
