iNFiNiT! Family Operation Manual
Revision D 15-27 Advanced Read FX
Using one EEFB:
• A single channel Roll may be mixed over a Full Page
message or RGB(A) graphic.
1
• A single channel Roll may be mixed over an RGB(A)
graphic and a live video source.
1
• A Crawl or Special Roll may be mixed over live video.
1
• Full Page messages may be displayed over live video
or an RGB(A) graphic.
2
• A single buffer Dissolve can be performed.
• Read Effects may be mixed with live video.
• A Wipe or Push can be executed over a static image
using one EEFB and
FG Effect (§15.8.7). The Out-
put Percentage levels of both the Foreground and
Background buffers of the EEFB can be independently
set to levels other than
0 and 100. This type of Read
Effect (
Wipe1 or Push1) can also be executed in
Multiple Effects
(§17.4.2).
• A Clock or Timer can be displayed in the Foreground
buffer over an image in the Background buffer. See
§11.2.3 for details.
• Using Intelligent Interface, serial data can be dis-
played in the Background buffer of an EEFB, while
other information is displayed in the Foreground
buffer.
3
NOTES
Special Rolls normally use two
standard frame buffers. However, in a
system equipped with one or more
1. See §9.3.6 and §9.4.8 for additional information on minimum buffer
requirements for Roll and Crawl operations.
2. See §15.8.5 and Section 20 for more information on the Video Input
Module option; and Section 21 for information on RGB Tools.
3. See §15.8.10 in this manual and §5.4 Serial Data Display (D) Com-
mands in the Intelligent Interface Option Handbook (Pub. No. 2A01989)
for more information.
