MIP with with bridge domain
•
MIP with circuit cross-connect (CCC)
•
MIP with bridge domain when maintenance association end point is configured
•
MIP with CCC when maintenance association end point is configured
The following sections describe MIP configuration:
•
Configuring the Maintenance Domain Bridge Domain on page 1130
•
Configuring the Maintenance Domain MIP Half Function on page 1130
•
Configuring the Maintenance Association Intermediate Points with Bridge
Domain on page 1131
•
Configuring the Maintenance Association Intermediate Points with Circuit
Cross-Connect on page 1131
•
Configuring the Maintenance Association Intermediate Points with Bridge Domain
when Maintenance Association End Point is Configured on page 1131
•
Configuring the Maintenance Intermediate Points with Circuit Cross-Connect when
Maintenance Association End Point is Configured on page 1132
Configuring the Maintenance Domain Bridge Domain
To configure the bridge domain, include the vlans statement at the [edit protocols oam
ethernetconnectivity-fault-management maintenance-domainmaintenance-domain-name]
hierarchy level.
NOTE: The Layer 2 CLI configurations and show commands for ACX5048
and ACX5096 routers differ compared to other ACX Series routers. For more
information, see “Understanding Layer 2 Next Generation Mode on ACX5048
and ACX5096 Routers” on page 1167.
Configuring the Maintenance Domain MIP Half Function
MIP Half Function (MHF) divides MIP functionality into two unidirectional segments,
improves visibility with minimal configuration, and improves network coverage by
increasing the number of points that can be monitored. MHF extends monitoring capability
by responding to loopback and linktrace messages to help isolate faults.
Whenever a MIP is configured and a bridge domain is mapped to multiple maintenance
domains or maintenance associations, it is essential that the MIP half function value for
all maintenance domains and maintenance associations be the same. To configure the
MIP half function, include the mip-half-function statement at the [edit protocols oam
ethernetconnectivity-fault-management maintenance-domainmaintenance-domain-name]
hierarchy level.
Copyright © 2017, Juniper Networks, Inc.1130
ACX Series Universal Access Router Configuration Guide
