interface-type

Syntax interface-type ds;

Hierarchy Level [edit interfaces interface-name partition partition-number]

[edit interfaces interface-name partition partition-number timeslots timeslot-range]

Release Information Statement introduced in Junos OS Release 12.3 for ACX Series Universal Access Routers.

Description For channelized interfaces only, configure the sublevel interface type.

NOTE: The partition statement is mandatory for configuring the sublevel

interface partition index.

Options ds—DS0 interface type.

Required Privilege

Level

interface—To view this statement in the configuration.

interface-control—To add this statement to the configuration.

Documentation

• show interfaces (T1, E1, or DS) on page 2506

• show interfaces (ATM) on page 2471
