Related
Documentation
Pseudowire Overview for ACX Series Universal Access Routers on page 590•
• Ethernet Pseudowire Overview on page 596
TDM Pseudowires Overview
A TDM pseudowire acts as Layer 2 circuit or service for T1 and E1 circuit signals across an
MPLS packet-switched network. On ACX Series routers, you configure a TDM pseudowire
with Structure-Agnostic Time Division Multiplexing (TDM) over Packet (SAToP) on the
ACX Series built-in channelized T1 and E1 interfaces. When you configure a TDM
pseudowire, the network between the customer edge (CE) routers appears transparent
to the CE routers, making it seem that the CE routers are directly connected. With the
SAToP configuration on the provider edge (PE) router’s T1 and E1 interfaces, the
interworking function (IWF) forms a payload (frame) that contains the CE router’s T1
and E1 Layer 1 data and control word. This data is transported to the remote PE over the
pseudowire. The remote PE removes all the Layer 2 and MPLS headers added in the
network cloud and forwards the control word and the Layer 1 data to the remote IWF,
which in turn forwards the data to the remote CE router.
Related
Documentation
Understanding Encapsulation on an Interface on page 104•
• SAToP Emulation on T1 and E1 Interfaces Overview on page 110
• Configuring SAToP Emulation on Channelized T1 and E1 Interfaces on page 191
• Pseudowire Overview for ACX Series Universal Access Routers on page 590
• ATM Pseudowire Overview on page 173
• Ethernet Pseudowire Overview on page 596
Example: TDM Pseudowire Base Configuration
•
Requirements on page 600
•
Overview of a TDM Pseudowire Base Configuration on page 600
•
Configuring an TDM Pseudowire on page 601
Requirements
The following is a list of the hardware and software requirements for this configuration.
•
One ACX Series router
•
Junos OS Release 12.2 or later
Overview of a TDM Pseudowire Base Configuration
The configuration shown here is the base configuration of an TDM pseudowire with T1
framing on an ACX Series router. This configuration is for one provider edge router. To
complete the TDM pseudowire configuration, you need to repeat this configuration on
an other provider edge router in the Multiprotocol Label Switched (MPLS) network.
Copyright © 2017, Juniper Networks, Inc.600
ACX Series Universal Access Router Configuration Guide
