Related
Documentation
RFC 2544-Based Benchmarking Tests Overview on page 1335•
• Layer 2 and Layer 3 RFC 2544-Based Benchmarking Test Overview on page 1338
• Configuring RFC 2544-Based Benchmarking Tests on page 1341
• show services rpm rfc2544-benchmarking on page 3156
• show services rpm rfc2544-benchmarking test-id on page 3161
Example: Configuring an RFC 2544-Based Benchmarking Test for Layer 3 IPv4 Services
This example shows how to configure the benchmarking test for a Layer 3 IPv4 service.
NOTE: This example is not applicable for ACX5048 and ACX5096 routers.
•
Requirements on page 1359
•
Overview on page 1359
•
Configuration on page 1360
•
Verifying the Results of the Benchmarking Test for Layer 3 IPv4 Services on page 1366
Requirements
This example uses the following hardware and software components:
•
An ACX Series router
•
Junos OS Release 12.3X53 or later
Overview
Consider a sample topology in which a router, Router A, functions as an initiator and
terminator of the test frames for an RFC 2544-based benchmarking test. Router A is
connected over a Layer 3 network to another router, Router B, which functions as a
reflector to reflect back the test frames it receives from Router A. IPv4 is used for
transmission of test frames over the Layer 3 network. This benchmarking test is used to
compute the IPv4 service parameters between Router A and Router B. Logical interfaces
on both the routers are configured with IPv4 addresses to measure the performance
attributes, such as throughput, latency, frame loss, and bursty frames, of network devices
for the IPv4 service.
Figure 71 on page 1360 shows the sample topology to perform an RFC 2544 test for a Layer
3 IPv4 service.
1359Copyright © 2017, Juniper Networks, Inc.
Chapter 37: Configuring RFC 2544-Based Benchmarking Tests
