You can configure PIM sparse mode globally or for a routing instance. This example
shows how to configure PIM sparse mode globally on all interfaces. It also shows how
to configure a static RP router and how to configure the non-RP routers.
To configure the router properties for PIM sparse mode:
1. Configure the static RP router.
[edit protocols pim]
user@host# set rp local family inet address 192.168.3.253
2. Configure the RP router interfaces. When configuring all interfaces, exclude the fxp0.0
management interface by including the disable statement for that interface.
[edit protocols pim]
user@host# set interface all mode sparse
user@host# set interface fxp0.0 disable
3. Configure the non-RP routers. Include the following configuration on all of the non-RP
routers.
[edit protocols pim]
user@host# set rp static address 192.168.3.253
user@host# set interface all mode sparse
user@host# set interface fxp0.0 disable
4. Monitor the operation of PIM sparse mode.
•
show pim interfaces
•
show pim join
•
show pim neighbors
•
show pim rps
Release History Table DescriptionRelease
Starting in Junos OS Release 16.1, PIM is disabled by default. When you
enable PIM, it operates in sparse mode by default.
16.1
Related
Documentation
Understanding PIM Sparse Mode on page 675•
Configuring BFD for PIM in ACX Series
The Bidirectional Forwarding Detection (BFD) Protocol is a simple hello mechanism that
detects failures in a network. BFD works with a wide variety of network environments
and topologies. A pair of routing devices exchanges BFD packets. Hello packets are sent
at a specified, regular interval. A neighbor failure is detected when the routing device
stops receiving a reply after a specified interval. The BFD failure detection timers have
683Copyright © 2017, Juniper Networks, Inc.
Chapter 22: Configuring Multicast Listener Discovery and Protocol-Independent Multicast
