vlan vlan-name; {
no-tag;
}
}
}
}
NOTE: In this method, the mirrored packet do not have any VLAN tags
associated with the packets.
Configuring Flow Mirroring on ACX5000 Series Routers
In the flow mirroring mode, input parameters for mirroring are specified through a firewall
filter. You need to include the port-mirroring CLI statement at the [edit forwarding-options]
hierarchy level. The ACX5000 line of routers supports only family ethernet-switching and
family inet configurations.
The following are the various methods to configure flow mirroring on ACX5000 line of
routers:
•
Configuring the Family as ethernet-switching and Specifying the Output as Layer 2
Logical Interface on page 1392
•
Configuring the Family as ethernet-switching and Specifying the Output as
VLAN. on page 1393
•
Configuring the Output as VLAN with the no-tag Option on page 1394
•
Configuring the Family as inet and Specifying the Output as Next-Hop IP
Address on page 1395
Configuring the Family as ethernet-switching and Specifying the Output as Layer
2 Logical Interface
You can configure flow mirroring on the ACX5000 line of routers by configuring the family
as ethernet-switching and specifying the output as a Layer 2 logical interface as shown
in the following configuration:
1. Configure the output as logical interface.
[edit forwarding-options]
port-mirroring {
family ethernet-switching {
output {
interface logical-interface-name;
}
}
}
2. Configure the firewall filter and specify the action as mirror.
[edit firewall]
family ethernet-switching {
filter filter-name {
Copyright © 2017, Juniper Networks, Inc.1392
ACX Series Universal Access Router Configuration Guide
