2. Configure the partition and the time slots, and set the interface type as ds.
[edit interfaces ce1-1/0/0:1:1]
user@host# set partition partition-number timeslots timeslots interface-type ds
For example:
[edit interfaces ce1-1/0/0:1:1]
user@host# set partition 1 timeslots 1-4 interface-type ds
NOTE: You can assign multiple time slots on a CE1 interface. In the set
command, separate the time slots by commas and do not include spaces
between them. For example:
[edit interfaces ce1-1/0/0:1:1]
user@host# set partition 1 timeslots 1-4,9,22-31 interface-type ds
To verify this configuration, use the show command at the [edit interfaces ce1-1/0/0:1:1
hierarchy level.
[edit interfaces ce1-1/0/0:1:1 ]
user@host# show
partition 1 timeslots 1-4 interface-type ds;
An NxDS0 interface can be configured from a channelized E1 interface (CE1). Here N
represents the number of time slots on the CE1 interface.
The value of N is 1 through 31 when a DS0 interface is configured from a CE1 interface.
After you partition the DS interface, configure the CESoPSN options.
Configuring CESoPSN on DS Interfaces
To configure CESoPSN encapsulation on a DS interface, include the encapsulation
statement at the [edit interfaces
ds-mpc-slot/mic-slot/port-number:channel:channel:channel] hierarchy level.
1. In configuration mode, go to the [edit interfaces
ds-mpc-slot/mic-slot/port-number:channel:channel:channel] hierarchy level.
[edit]
user@host# edit interfaces ds-mpc-slot/mic-slot/port-number:channel:channel:channel
For example:
[edit]
user@host# edit interfaces ds-1/0/0:1:1:1
2. Configure CESoPSN as the encapsulation type and then set the logical interface for
the ds interface.
[edit interfaces ds-1/0/0:1:1:1 ]
user@host# set encapsulation cesopsn unit interface-unit-number
