Understanding Interfaces on ACX Series Universal Access Routers
The ACX Series routers support time-division multiplexing (TDM) T1 and E1 interfaces
and Ethernet (1 GbE copper, 1GbE, 10 GbE, and 40 GbE fiber) interfaces to support both
the legacy and evolution needs of the mobile network. Support for Power over Ethernet
(PoE+) at 65 watts per port mitigates the need for additional electrical cabling for
microwaves or other access interfaces.
The ACX Series routers support the following:
•
TDM T1 and E1 ports:
•
The ACX1000 router contains eight T1 or E1 ports.
•
The ACX2000 router contains 16 T1 or E1 ports.
•
Inverse Multiplexing for ATM (IMA)
NOTE: ACX5048 and ACX5096 routers do not support T1 or E1 ports and
Inverse Multiplexing for ATM (IMA).
•
Gigabit Ethernet ports:
•
The ACX1000 router contains eight Gigabit Ethernet ports. The ACX1000 router also
supports either four RJ45 (Cu) ports or installation of four Gigabit Ethernet small
form-factor pluggable (SFP) transceivers.
•
The ACX2000 router contains 16 Gigabit Ethernet ports and two PoE ports. The
ACX2000 router also supports installation of two Gigabit Ethernet SFP transceivers
and two 10-Gigabit Ethernet SFP+ transceivers.
NOTE: 40GbE is supported only on ACX5048 and ACX5096 routers.
