Table 16: Encapsulation Overhead by Encapsulation Type (continued)

Encapsulation Overhead (Bytes)Interface Encapsulation

4Ethernet circuit cross-connect (CCC) and virtual private

LAN service (VPLS)

32Ethernet over ATM

22Ethernet SNAP

18Ethernet translational cross-connect (TCC)

14Ethernet version 2

4Extended virtual local area network (VLAN) CCC and

VPLS

22Extended VLAN TCC

4Frame Relay

4PPP

4VLAN CCC

4VLAN VPLS

22VLAN TCC

Media MTU Sizes by Interface Type for ACX Series Routers

Table 17: Media MTU Sizes by Interface Type for ACX Series Routers

Default IP Protocol

MTU (Bytes)

Maximum MTU

(Bytes)

Default Media

MTU (Bytes)Interface Type

1500 (IPv4),

1497 (ISO)

91921514Gigabit Ethernet

1500 (IPv4),

1497 (ISO)

9192151410-Gigabit Ethernet
