vpls {

site-range 10;

site green3 {

site-identifier 3;

}

Interface ae0.0 represents the aggregated Ethernet interface in the routing instance

configuration. The VPLS routing instance configuration is otherwise standard.

Configuring VLAN Identifiers for VLANs and VPLS Routing Instances in ACX Series

You can configure VLAN identifiers for a VLAN or a VPLS routing instance in the following

ways:

•

By using either the vlan-id statement or the vlan-tags statement to configure a

normalizing VLAN identifier. This topic describes how normalizing VLAN identifiers are

processed and translated in a VLAN or a VPLS routing instance.

•

By using the input-vlan-map and the output-vlan-map statements at the [edit interfaces

interface-name unit logic-unit-number] or [edit logical-systems logical-system-name

interfaces interface-name unit logic-unit-number] hierarchy level to configure VLAN

mapping.

NOTE: In ACX5048 and ACX5096 routers,VLAN map operation is supported

only if the connectivity-type is ce mode and not with permanent mode.

The vlan-id and vlan-tags statements are used to specify the normalizing VLAN identifier

under the VLAN or VPLS routing instance. The normalizing VLAN identifier can translate

or normalize the VLAN tags of packets received into a learn VLAN identifier.

NOTE: You cannot configure VLAN mapping using the input-vlan-map and

output-vlan-map statements if you configure a normalizing VLAN identifier

for a VLAN or VPLS routing instance using the vlan-id or vlan-tags statements.

To configure a VLAN identifier for a VLAN, include either the vlan-id or the vlan-tags

statement at the [edit interfaces interface-name unit logic-unit-number] or [edit

logical-systems logical-system-name interfaces interface-name unit logic-unit-number]

hierarchy level, and then include that logical interface in the VLAN configuration.

For a VPLS routing instance, include either the vlan-id or vlan-tags statement at the [edit

interfaces interface-name unit logic-unit-number] or [edit logical-systems

logical-system-name interfaces interface-name unit logic-unit-number] hierarchy level, and

then include that logical interface in the VPLS routing instance configuration.
