jitter-buffer-packets—Number of packets in the jitter buffer (from 1 through 64
packets).
•
packetization-latency—Time required to create packets (from 1000 through 8000
microseconds).
•
payload-size—Payload size for virtual circuits that terminate on Layer 2 interworking
(iw) logical interfaces (from 32 through 1024 bytes).
NOTE: This topic shows the configuration of only one CESoPSN option.
You can follow the same method to configure all the other CESoPSN
options.
[edit interfaces ds-fpc-slot/pic-slot/port:channel cesopsn-options]
user@host# set excessive-packet-loss-rate sample-period sample-period
For example:
[edit interfaces ds-1/0/0:1:1:1 cesopsn-options]
user@host# set excessive-packet-loss-rate sample-period 4000
To verify the configuration using the values shown in the examples, use the show
command at the [edit interfaces ds-1/0/0:1:1:1] hierarchy level:
[edit interfaces ds-1/0/0:1:1:1]
user@host# show
cesopsn-options {
excessive-packet-loss-rate {
sample-period 4000;
}
}
Configuring the Pseudowire Interface
To configure the TDM pseudowire at the provider edge (PE) router, use the existing
Layer 2 circuit infrastructure, as shown in the following procedure:
1. In configuration mode, go to the [edit protocols l2circuit] hierarchy level.
[edit]
user@host# edit protocol l2circuit
2. Configure the IP address of the neighboring router or switch, the interface forming the
Layer 2 circuit, and the identifier for the Layer 2 circuit.
[edit protocol l2circuit]
user@host# set neighbor ip-address interface
interface-name-fpc-slot/pic-slot/port.interface-unit-number virtual-circuit-id
virtual-circuit-id
For example:
[edit protocol l2circuit]
user@host# set neighbor 10.255.0.6 interface ds-1/0/0:1:1:1 virtual-circuit-id 1
