Table 14: CLI Equivalents of Terms Used in Documentation for an ACX5096 Router
Additional InformationItem in Documentation
Value (as displayed
in the CLI)
Description (as
displayed in the CLI)
Hardware
Item (as
displayed in
the CLI)
Chassis Physical Specifications
for an ACX5000 Router
Router chassis–ACX5096Chassis
Interface Naming Conventions
Used in the Junos OS
Operational Commands
The router does not have
actual FPCs. In this case,
FPC refers to the router
itself.
Value of n is always 0.Abbreviated name of
the Flexible PIC
Concentrator (FPC)
FPC (n)
Interface Naming Conventions
Used in the Junos OS
Operational Commands
The router does not have
actual PIC devices; see
entries for PIC 0 for the
equivalent item on the
router.
Value of n is always 0.Abbreviated name of
the Physical Interface
Card (PIC)
PIC (n)
ACX5000 Universal Access
Router Overview
Built-in network ports on
the front panel of the
router
PIC 096x10G–8x40G
Port and Interface
Specifications
Optical transceiversn is a value equivalent
to the number of the
port in which the
transceiver is installed.
Abbreviated name of
the transceiver
Xcvr (n)
AC Power Supply for an
ACX5000 Router
DC Power Supply for an
ACX5000 Router
AC power supply
DC power supply
n is a value in the
range of 0-1.
Built-in power supplyPower
supply (n)
Cooling System and Airflow in
an ACX5000 Router
Fann is a value in the
range of 0-2 for
ACX5096
FanFan
Figure 13: ACX5096 Interface Port Mapping
3—1— 40 Gigabit Ethernet ports (8)Electrostatic Discharge (ESD) terminal
2—10 Gigabit Ethernet ports (96)
