receive-failure-threshold (RFC 2544 Benchmarking)

Syntax receive-failure-threshold;

Hierarchy Level [edit services rpm rfc2544-benchmarkingtests test-name test-name]

Release Information Statement introduced in Junos OS Release 12.3X53 for ACX Series routers.

Description Specifies the failure threshold value of the received test frames.

Required Privilege

Level

interface—To view this statement in the configuration.

interface-control—To add this statement to the configuration.

Documentation

• RFC 2544-Based Benchmarking Tests Overview on page 1335

• Configuring RFC 2544-Based Benchmarking Tests on page 1341

• rfc2544-benchmarking on page 1698
