user@host# set interfaces lt-0/0/10 unit 0 encapsulation vlan-bridge
user@host# set interfaces lt-0/0/10 unit 0 vlan-id 101
user@host# set interfaces lt-0/0/10 unit 0 peer-unit 1
user@host# set interfaces lt-0/0/10 unit 1 encapsulation vlan-ccc
user@host# set interfaces lt-0/0/10 unit 1 vlan-id 101
user@host# set interfaces lt-0/0/10 unit 1 peer-unit 0
2. Create an IRB interface.
[edit]
user@host# set interfaces irb unit 0 family inet address 192.168.1.2/24
3. Associate the IRB interface to a bridge domain.
[edit]
user@host# set bridge-domains b1 vlan-id 101
user@host# set bridge-domains b1 interface lt-0/0/10.0
user@host# set bridge-domains b1 routing-interface irb.0
Associating the Proxy Logical Interface to a Logical Interface in a VRF Domain
To associate the proxy logical interface to a logical interface in a VRF domain, you need
to run the following PFE commands:
•
test pfe acx vrf-mc-leak enable—Enables proxy association.
•
test pfe acx entry add VRF-logical-interface-name logical-tunnel-logical-interface-name
IRB-logical-interface-name IRB-IP-address + 1—Creates an association between proxy
logical interface and the logical interface in a VRF domain.
•
test pfe acx vrf-mc-leak disable—Disables proxy association.
•
test pfe acx entry del VRF-logical-interface-name logical-tunnel-logical-interface-name
IRB-logical-interface-name IRB-IP-address + 1—Deletes the association between the
proxy logical interface and the logical interface in a VRF domain.
•
show pfe vrf-mc-leak—Displays the association entries between proxy logical interface
and the logical interface in a VRF domain.
NOTE: When the router or PFE is rebooted, the proxy associations of logical
interfaces is removed and you need to once again create the proxy
associations of logical interface.
Limitations
The following limitations need to be considered for receiving multicast traffic in a VRF
domain:
•
Maximum of 5 proxy associations of logical interfaces can be configured.
•
VRF IPv6 multicast is not supported.
141Copyright © 2017, Juniper Networks, Inc.
Chapter 4: Configuring Interfaces and Chassis
