External Clock Synchronization Overview for ACX Series Routers on page 226•
• synchronization on page 1739
• Interface and Router Clock Sources Overview
IEEE 1588v2 PTP Boundary Clock Overview
The IEEE 1588v2 standard defines the Precision Time Protocol (PTP), which is used to
synchronize clocks throughout a network. The standard describes the PTP boundary
clock’s hierarchical master/slave architecture for the distribution of time-of-day.
•
IEEE 1588v2 PTP Boundary Clock on page 234
•
Clock Clients on page 236
IEEE 1588v2 PTP Boundary Clock
Starting with Junos OS Release 17.3R1, IEEE 1588v2 boundary clock is supported on
QFX10002 switches. An IEEE 1588v2 boundary clock has multiple network connections
and can act as a source (master) and a destination (slave or client) for synchronization
messages. It synchronizes itself to a best master clock through a slave port and supports
synchronization of remote clock clients to it on master ports. Boundary clocks can improve
the accuracy of clock synchronization by reducing the number of 1588v2-unaware hops
between the master and the client. Boundary clocks can also be deployed to deliver
better scale because they reduce the number of sessions and the number of packets per
second on the master.
The boundary clock intercepts and processes all PTP messages and passes all other
traffic. The best master clock algorithm (BMCA) is used by the boundary clock to select
the best configured acceptable master clock that a boundary slave port can see. To
configure a boundary clock, include the boundary statement at the [edit protocols ptp
clock-mode] hierarchy level and at least one master with the master statement and at
least one slave with the slave statement at the [edit protocols ptp] hierarchy level.
Figure 21 on page 235 illustrates two boundary clocks in a network in which the clock flow
is from the upstream node (BC-1) to the downstream node (BC-2).
NOTE: This figure also applies to MX Series routers and QFX Series switches.
Copyright © 2017, Juniper Networks, Inc.234
