Example: Configuring IEEE 802.3ah OAM Support for an Interface
Junos OS for ACX Series routers allows the Ethernet interfaces on these routers to support
the IEEE 802.3ah standard for the Operation, Administration, and Maintenance (OAM)
of Ethernet in access networks. The standard defines OAM link fault management (LFM).
You can configure IEEE 802.3ah OAM LFM on point-to-point Ethernet links that are
connected either directly or through Ethernet repeaters.
This example describes how to enable and configure OAM on a Gigabit Ethernet interface.
Requirements
This example uses the following hardware and software components:
•
Junos OS Release 12.2 or later for ACX Series routers.
•
An ACX1000 or ACX2000 router.
Overview and Topology
In this example, you configure a 10-Gigabit Ethernet interface on an ACX Series router
with 802.3ah OAM support, which includes: link discovery, protocol data units (PDUs),
remote loopback, negotiation, and event thresholds.
Configuring IEEE 802.3ah OAM on an ACX Series Router
CLI Quick
Configuration
To quickly configure IEEE 802.3ah Ethernet OAM, copy the following commands and
paste them into the CLI:
edit
edit protocols oam ethernet link-fault-management
set interface xe-0/0/0 link-discovery active pdu-interval 800 pdu-threshold 4
remote-loopback negotiation-options allow-remote-loopback
set interface xe-0/0/0 event-thresholds frame-error 30 frame-period 50
frame-period-summary 40 symbol-period 20
1133Copyright © 2017, Juniper Networks, Inc.
Chapter 34: Configuring Operations, Administration, and Management (OAM)
