Table 97: jnxSoamDmCurrentStatsTable (continued)
DescriptionObject IDObject
Contains the average two-way
inter-frame delay interval calculated by
this MEP for this Measurement Interval.
The value of this object is undefined when
jnxSoamDmCfgType is dm1DmTx or
dm1DmRx.
jnxSoamDmCurrentStatsEntry 22jnxSoamDmCurrentStatsIfdvTwoWayAvg
Contains the count of the number of
SOAM PDUs sent during this
Measurement Interval. This object applies
when jnxSoamDmCfgType is dmDmm or
dm1DmTx and is undefined if
jnxSoamDmCfgType is dm1DmRx. It
indicates the number of DMM or 1DM
SOAM frames transmitted.
jnxSoamDmCurrentStatsEntry 23jnxSoamDmCurrentStatsSoamPdusSent
Contains the count of the number of
SOAM PDUs received in this
Measurement Interval. This object
indicates the number of DMR and 1DM
SOAM frames received. This object
applies when jnxSoamDmCfgType is
dmDmm or dm1DmRx and is undefined
if jnxSoamDmCfgTypeis dm1DmTx.
jnxSoamDmCurrentStatsEntry 24jnxSoamDmCurrentStatsSoamPdusReceived
Managed Objects for jnxSoamDmHistoryStatsTable
The jnxSoamDmHistoryStatsTable, whose object identifier is {jnxSoamPmLmObjects 4},
contains the jnxSoamDmHistoryStatsEntry that signifies the Ethernet delay measurement
(ETH-DM) historical statistical details. Each jnxSoamDmHistoryStatsEntry, whose object
identifier is {jnxSoamDmHistoryStatsTable 1}, contains the objects listed in the following
table.
The jnxSoamDmHistoryStatsTable contains the results for history Measurement Intervals
in a SOAM Loss Measurement session. Rows of this table object are created automatically
by the SNMP Agent when the Loss Measurement session is running and a Measurement
Interval is completed. Each row in the table represents the history statistics for a Loss
Measurement session Measurement Interval for the defined MEP. This table uses five
indices. The first three indices are the indices of the Maintenance Domain, MaNet, and
MEP tables. The fourth index is the specific LM session on the selected MEP. The fifth
index index the specific Measurement Interval.
At least 32 completed Measurement Intervals are to be supported. 96 completed
Measurement Intervals are recommended to be supported. If there are at least 32 rows
in the table and a new Measurement Interval completes and a new row is to be added
to the table, the oldest completed Measurement Interval may be deleted (row deletion).
If the measurement interval is other than 15 minutes then a minimum of 8 hours of
completed Measurement Intervals are to be supported and 24 hours are recommended
to be supported.
1211Copyright © 2017, Juniper Networks, Inc.
Chapter 34: Configuring Operations, Administration, and Management (OAM)
