Table 93: jnxSoamLmCurrentStatsTable (continued)
DescriptionObject IDObject
Contains the count of the number of
SOAM PDUs sent during this
Measurement Interval. This object applies
when jnxSoamLmCfgType is lmLmm,
lmSlm, or lmCcm. It indicates the number
of LMM, CCM, or SLM SOAM frames
transmitted.
jnxSoamLmCurrentStatsEntry 15jnxSoamLmCurrentStatsSoamPdusSent
Contains the count of the number of
SOAM PDUs received in this
Measurement Interval. This object applies
when jnxSoamLmCfgType is lmLmm,
lmSlm, or lmCcm. This object indicates
the number of LMR, CCM, or SLR SOAM
frames received.
jnxSoamLmCurrentStatsEntry 16jnxSoamLmCurrentStatsSoamPdusReceived
Managed Objects for jnxSoamLmHistoryStatsTable
The jnxSoamLmHistoryStatsTable, whose object identifier is {jnxSoamPmLmObjects 4},
contains the jnxSoamLmHistoryStatsEntry that signifies the Ethernet loss measurement
(ETH-LM) historical statistical details. Each jnxSoamLmHistoryStatsEntry, whose object
identifier is {jnxSoamLmHistoryStatsTable 1}, contains the objects listed in the following
table.
The jnxSoamLmHistoryStatsTable contains the results for history Measurement Intervals
in a SOAM Loss Measurement session. Rows of this table object are created automatically
by the SNMP Agent when the Loss Measurement session is running and a Measurement
Interval is completed. Each row in the table represents the history statistics for a Loss
Measurement session Measurement Interval for the defined MEP. This table uses five
indices. The first three indices are the indices of the Maintenance Domain, MaNet, and
MEP tables. The fourth index is the specific LM session on the selected MEP. The fifth
index index the specific Measurement Interval.
At least 32 completed Measurement Intervals are to be supported. 96 completed
Measurement Intervals are recommended to be supported. If there are at least 32 rows
in the table and a new Measurement Interval completes and a new row is to be added
to the table, the oldest completed Measurement Interval may be deleted (row deletion).
If the measurement interval is other than 15 minutes then a minimum of 8 hours of
completed Measurement Intervals are to be supported and 24 hours are recommended
to be supported.
Except for jnxSoamLmHistoryStatsIndex, jnxSoamLmHistoryStatsEndTime,
jnxSoamLmHistoryStatsElapsedTime and jnxSoamLmHistoryStatsSuspect, each object
in this table applies only if the corresponding bit is set in
jnxSoamLmCfgMeasurementEnable. The rows and objects in this table are to be persistent
upon reboot or restart of a device.
