Configuring Interfaces for VPLS Routing in ACX Series
On each PE router and for each VPLS routing instance, specify which interfaces are
intended for the VPLS traffic traveling between PE and CE routers. To specify the interface
for VPLS traffic, include the interface statement in the routing instance configuration:
interface interface-name;
You can include this statement at the following hierarchy levels:
•
[edit routing-instances routing-instance-name]
•
[edit logical-systems logical-system-name routing-instances routing-instance-name]
NOTE: ACX Series routers do not support the [edit logical-systems] hierarchy.
You must also define each interface by including the following statements:
vlan-tagging;
encapsulation encapsulation-type;
unit logical-unit-number {
family vpls;
vlan-id vlan-id-number;
}
You can include these statements at the following hierarchy levels:
•
[edit interfaces interface-name]
•
[edit logical-systems logical-system-name interfaces interface-name]
NOTE: ACX Series routers do not support the [edit logical-systems] hierarchy.
The following sections provide enough information to enable you to configure interfaces
for VPLS routing. For detailed information about configuring interfaces and the statements
at the [edit interfaces] hierarchy level, see the Junos OS Network Interfaces Library for
Routing Devices.
•
Configuring the VPLS Interface Name on page 1256
•
Configuring VPLS Interface Encapsulation on page 1256
•
Enabling Flexible VLAN Tagging on page 1258
•
Configuring VLAN IDs for Logical Interfaces on page 1259
•
Sample Scenario of Hierarchical Virtual Private LAN Service on Logical Tunnel
Interface on page 1259
•
Configuring Aggregated Ethernet Interfaces for VPLS on page 1261
1255Copyright © 2017, Juniper Networks, Inc.
Chapter 35: Configuring Virtual Private LAN Service
