Table 96: jnxSoamDmMeasuredStatsTable (continued)
DescriptionObject IDObject
Contains the last one-way inter-frame
delay interval in the backward direction
calculated by this MEP. The value of this
object is undefined when
jnxSoamDmCfgType is dm1DmTx or or
dm1DmRx.
jnxSoamDmMeasuredStatsEntry
6
jnxSoamDmMeasuredStatsIfdvBackward
Managed Objects for jnxSoamDmCurrentStatsTable
The jnxSoamDmCurrentStatsTable, whose object identifier is {jnxSoamPmDmObjects
3}, contains the jnxSoamDmCurrentStatsEntry that signifies the Ethernet delay
measurement (ETH-DM) historical statistical details. Each jnxSoamDmCurrentStatsEntry,
whose object identifier is {jnxSoamDmCurrentStatsTable 1}, contains the objects listed
in the following table.
The jnxSoamDmCurrentStatsTable contains the results for the current Measurement
Interval in a SOAM Delay Measurement session gathered during the interval indicated
by iterator count. A row in this table is created automatically by the SNMP Agent when
the Delay Measurement session is configured. Each row in the table represents the current
statistics for a Delay Measurement session for the defined MEP. This table uses four
indices. The first three indices are the indices of the Maintenance Domain, MaNet, and
MEP tables. The fourth index is the specific DM session on the selected MEP. There can
be more than one DM session per MEP. The objects in this table apply regardless of the
value of jnxSoamDmCfgType unless otherwise specified in the object description.
Backward and two-way statistic objects are undefined if jnxSoamDmCfgType is
dm1DmRx. Except for jnxSoamDmCurrentStatsIndex, jnxSoamDmCurrentStatsStartTime
jnxSoamDmCurrentStatsElapsedTime and jnxSoamDmCurrentStatsSuspect, each
object in this table applies only if the corresponding bit is set in
jnxSoamDmCfgMeasurementEnable. The objects in this table do not need to be persistent
upon reboot or restart of a device.
Table 97: jnxSoamDmCurrentStatsTable
DescriptionObject IDObject
Specifies the index for the Measurement
Interval within this PM session. This value
will become the value for
jnxSoamDmHistoryStatsIndex once the
Measurement Interval is completed.
Measurement Interval indexes are
assigned sequentially by the SNMP
Agent. The first Measurement Interval
that occurs after the session is started is
assigned index 1.
jnxSoamDmCurrentStatsEntry 1jnxSoamDmCurrentStatsIndex
Specifies the time at which the
Measurement Interval started.
jnxSoamDmCurrentStatsEntry 2jnxSoamDmCurrentStatsStartTime
1207Copyright © 2017, Juniper Networks, Inc.
Chapter 34: Configuring Operations, Administration, and Management (OAM)
