To configure the profile that you want, enter and commit the following statement:
[edit]
user@host# set chassis forwarding-options profile-name profile-name
NOTE: When you configure and commit a profile, the Packet Forwarding
Engine (PFE) process restarts and all the data interfaces on the router go
down and come back up.
The settings for l2-profile-three are configured by default. That is, if you do not configure
the forwarding–options chassis profile-name statement, the l2-profile-three profile settings
are configured.
Interpreting the Enterprise-Specific Service OAM MIB
Junos OS supports the generation of SNMP traps and alarms for performance monitoring
(PM) functionalities using MIB objects to manage Service Operations, Administration,
and Maintenance (OAM) capabilities that are in conformance with the service OAM
requirements and framework specified by Metro Ethernet Forum (MEF) 17, service OAM
performance monitoring requirements defined by SOAM-PM, and the service OAM
management objects specified in Technical Specification MEF 7.1. Junos OS supports an
enterprise-specific MIB, SOAM PM MIB, that defines the management objects for Ethernet
services operations, administration, and maintenance for performance monitoring. SNMP
support is available for the MIB objects defined in Technical Specification MEF 36.
•
Service OAM MIB on page 1171
•
Managed Objects for jnxSoamPmMepTable on page 1172
•
Managed Objects for jnxSoamLmCfgTable on page 1174
•
Managed Objects for jnxSoamLmMeasuredStatsTable on page 1184
•
Managed Objects for jnxSoamLmCurrentStatsTable on page 1185
•
Managed Objects for jnxSoamLmHistoryStatsTable on page 1188
•
Managed Objects for jnxSoamDmCfgTable on page 1191
•
Managed Objects for jnxSoamDmMeasuredStatsTable on page 1205
•
Managed Objects for jnxSoamDmCurrentStatsTable on page 1207
•
Managed Objects for jnxSoamDmHistoryStatsTable on page 1211
•
Managed Objects for jnxSoamLmThresholdCfgTable on page 1216
•
Managed Objects for jnxSoamDmThresholdCfgTable on page 1219
•
Managed Objects for jnxSoamPmNotificationObj Table on page 1226
•
Managed Objects for jnxSoamPmNotifications Table on page 1227
Service OAM MIB
The Juniper Networks enterprise-specific service operations, administration, and
maintenance (OAM) MIB (jnxSoamPmMib) whose object ID is {jnxMibs 78}, defines for
the management of Ethernet services operations, administration and maintenance for
1171Copyright © 2017, Juniper Networks, Inc.
Chapter 34: Configuring Operations, Administration, and Management (OAM)
