Configuring an TDM Pseudowire
CLI Quick
Configuration
To quickly configure this example, copy the following commands, paste them in a text
file, remove any line breaks, change any details necessary to match your network
configuration, and then copy and paste the commands into the CLI at the [edit] hierarchy
level:
set chassis fpc 0 pic 0 framing t1
set interfaces ct1-0/0/0 no-partition interface-type t1
set interfaces t1-0/0/0 encapsulation satop
set interfaces t1-0/0/0 unit 0
set interfaces ge-0/2/0 unit 0 family inet address 20.1.1.2/24
set interfaces ge-0/2/0 unit 0 family mpls
set interfaces lo0 unit 0 family inet address 70.1.1.1/32
set protocols rsvp interface ge-0/2/0.0
set protocols mpls no-cspf
set protocols mpls label-switched-path PE1-to-PE2 to 40.1.1.1
set protocols mpls interface ge-0/2/0.0
set protocols ospf traffic-engineering
set protocols ospf area 0.0.0.0 interface ge-0/2/0.0
set protocols ospf area 0.0.0.0 interface lo0.0 passive
set protocols ldp interface ge-0/2/0.0
set protocols ldp interface lo0.0
set protocols l2circuit neighbor 40.1.1.1 interface t1-0/0/0.0 virtual-circuit-id
1
NOTE: To configure a TDM pseudowire with E1 framing, include the e1
statement at the [edit chassis fpc 0 pic 0 framing] hierarchy level instead of
the t1 statement shown in this example.
Step-by-Step
Procedure
Configure the framing format:
[edit]
1.
user@host# edit chassis
[edit chassis]
user@host# set fpc 0 pic 0 framing t1
2. Create a T1 interface on a channelized T1 interface (ct1) and enable full
channelization with the no-partition statement. On the logical T1 interface, set the
Structure-Agnostic TDM over Packet (SAToP) encapsulation mode.
[edit]
user@host# edit interfaces
[edit interfaces]
user@host# set ct1-0/0/0 no-partition interface-type t1
user@host# set t1-0/0/0 encapsulation satop
user@host# set t1-0/0/0 unit 0
601Copyright © 2017, Juniper Networks, Inc.
