Table 142: show filter aggregate policer Output Fields (continued)
Field DescriptionField Name
Committed information rate in kilobytes per secondCIR
Peak burst size in kilobytesPBS
Peak information rate in kilobytes per secondPIR
Unique number that signifies the mode of hierarchical policer. 1
indicates bandwidth guarantee mode, 2 denotes peak mode, and
3 signifies hybrid mode
Agg mode
Details of the parent aggregate policerPARENT
Name of the aggregate policer that functions as the parent policerpolicer-name
Peak burst size in kilobytesPBS
Peak information rate in kilobytes per secondPIR
Total value of CIR and CBS of all child policers referenced by the
parent policer in kilobytes per second and kilobytes respectively
Sum child CIR and CBS
Total value of PIR and PBS of all child policers referenced by the
parent policer in kilobytes per second and kilobytes respectively
Sum child PIR and PBS
Maximum value of CIR and CBS of all child policers referenced by
the parent policer in kilobytes per second and kilobytes respectively
Max child CIR and CBS
Maximum value of PIR and PBS of all child policers referenced by
the parent policer in kilobytes per second and kilobytes respectively
Max child PIR and PBS
Denotes the comparative details of child, parent, and aggregate
policers for the peak burst size and committed burst size. This
statistical information enables you to calibrate the values
appropriately for the different policers to enable the mode of
hierarchical policy that you want to be applied properly.
RESULTS
Denotes whether the parameters of the child and parent policers
conform with the requirements and guidelines of the different
hierarchical policer modes. Any warnings are displayed, which
enables you to modify the policer settings
STATUS
Sample Output
show filter aggregate-policer policer-name (With Warnings)
user@host> show filter aggregate-policer p1
CHILDREN
-------
2467Copyright © 2017, Juniper Networks, Inc.
Chapter 42: Operational Commands
