Table 150: show interfaces Gigabit Ethernet Output Fields (continued)
Level of OutputField DescriptionField Name
detail extensiveOTN FEC excessive or degraded error alarms triggered on the interface.
• FEC Degrade—OTU FEC Degrade defect.
• FEC Excessive—OTU FEC Excessive Error defect.
OTN FEC alarms
detail extensiveOTN OC defects triggered on the interface.
• LOS—OC Loss of Signal defect.
• LOF—OC Loss of Frame defect.
• LOM—OC Loss of Multiframe defect.
• Wavelength Lock—OC Wavelength Lock defect.
OTN OC
detail extensiveOTN OTU defects detected on the interface
• AIS—OTN AIS alarm.
• BDI—OTN OTU BDI alarm.
• IAE—OTN OTU IAE alarm.
• TTIM—OTN OTU TTIM alarm.
• SF—OTN ODU bit error rate fault alarm.
• SD—OTN ODU bit error rate defect alarm.
• TCA-ES—OTN ODU ES threshold alarm.
• TCA-SES—OTN ODU SES threshold alarm.
• TCA-UAS—OTN ODU UAS threshold alarm.
• TCA-BBE—OTN ODU BBE threshold alarm.
• BIP—OTN ODU BIP threshold alarm.
• BBE—OTN OTU BBE threshold alarm.
• ES—OTN OTU ES threshold alarm.
• SES—OTN OTU SES threshold alarm.
• UAS—OTN OTU UAS threshold alarm.
OTN OTU
detail extensiveDestination Access Port Interface (DAPI) from which the packets were received.Received DAPI
detail extensiveSource Access Port Interface (SAPI) from which the packets were received.Received SAPI
detail extensiveDestination Access Port Interface (DAPI) to which the packets were transmitted.Transmitted DAPI
detail extensiveSource Access Port Interface (SAPI) to which the packets were transmitted.Transmitted SAPI
detail extensive(10-Gigabit Ethernet interfaces) Displays Physical Coding Sublayer (PCS) fault
conditions from the WAN PHY or the LAN PHY device.
• Bit errors—The number of seconds during which at least one bit error rate
(BER) occurred while the PCS receiver is operating in normal mode.
• Errored blocks—The number of seconds when at least one errored block
occurred while the PCS receiver is operating in normal mode.
PCS statistics
