Table 197: show poe controller Output Fields (continued)
Field DescriptionField Name
Total amount of power being consumed by the PoE ports at the time the
command is executed. This value, which represents actual power consumption,
cannot exceed the value for Maximum power.
Powerconsumption
Amount of power that has been placed in reserve for power demand spikes and
that cannot be allocated to a PoE interface.
Guard Band
Power management mode: class or static or high-power.
NOTE: The mode high-power is available on only ACX2000 routers.
Management
Status of the PoE controller:
• AF_ENHANCE—Controller supports enhanced PoE. The maximum power per
PoE port is 18.6 W in static mode (15.4 W in class mode).
• DEVICE FAIL—Software download to the controller has failed or the PoE
controller is not initialized because of a hardware failure.
• DOWNLOAD_INIT—Software download to the controller is in the initial phase.
• AF_MODE—Controller supports standard IEEE 802.3af. The maximum power
per PoE port is 15.4 W.
• AT/AF COMBO—Controller supports a mix of standard IEEE 802.3af and IEEE
802.3at (PoE+) ports. The maximum power per port is 30 W for IEEE 802.3at
(PoE+) ports and 15.4 W for the IEEE 802.3af ports.
• AT_MODE—Controller supports IEEE 802.3at (PoE+). The maximum power
per PoE port is 30 W.
• SW_DOWNLOAD (n%)—Software download to the controller is in progress.
Status
Link Layer Discovery Protocol (LLDP) priority operating state. The state can be
Enabled or Disabled.
LLDP priority enables the PoE controller to assign interfaces the power priority
provided by the connected powered device by using LLDP power negotiation
rather than the power priority configured on the switch interface.
Lldp Priority
Sample Output
show poe controller (EX3200 Switch)
user@switch> show poe controller
Controller Maximum Power Guard Management Status Lldp
index power consumption band Priority
0 130.00W 81.20W 10W Static AF_ENHANCE Disabled
show poe controller (EX8200 Switch)
user@switch> show poe controller
Controller Maximum Power Guard Management Status Lldp
index power consumption band Priority
0 792.00W 603.50W 0W Class AT/AF COMBO Disabled
4 915.00W 781.00W 0W Class AT/AF COMBO Disabled
7 915.00W 0.00W 0W Class AT/AF COMBO Disabled
