Table 199: show ppp interface Output Fields (continued)
Level of
OutputField DescriptionField Name
extensiveLCP information:
• State—LCP protocol state (all platforms except M120 and M320 routers):
• Ack-rcvd—A Configure-Request has been sent and a Configure-Ack has been received.
• Ack-sent—A Configure-Request and a Configure-Ack have both been sent, but a
Configure-Ack has not yet been received.
• Closed—Link is not available for traffic.
• Opened—Link is administratively available for traffic.
• Req-sent—An attempt has been made to configure the connection.
• State—LCP protocol state (M120 and M320 routers):
• Ack-rcvd—A Configure-Request has been sent and a Configure-Ack has been received.
• Ack-sent—A Configure-Request and a Configure-Ack have both been sent, but a
Configure-Ack has not yet been received.
• Closed—Link is available (up), but no Open has occurred.
• Closing—A Terminate-Request has been sent but a Terminate-Ack has not yet been
received.
• Opened—Link is administratively available for traffic. A Configure-Ack has been both
sent and received.
• Req-sent—An attempt has been made to configure the connection. A Configure-Request
has been sent but a Configure-Ack has not yet been received.
• Starting—An administrative Open has been initiated, but the lower layer is still unavailable
(Down).
• Stopped—The system is waiting for a Down event after the This-Layer-Finished action,
or after sending a Terminate-Ack.
• Stopping—A Terminate-Request has been sent but a Terminate-Ack has not yet been
received.
• Last started—LCP state start time.
• Last completed—LCP state completion time.
LCP
