Table 199: show ppp interface Output Fields (continued)
Level of
OutputField DescriptionField Name
extensiveInternet Protocol version 6 Control Protocol (IPv6CP) information.
• State—(All platforms except M120 and M320 routers) One of the following values:
• Ack-rcvd—A Configure-Request has been sent and a Configure-Ack has been received.
• Ack-sent—A Configure-Request and a Configure-Ack have both been sent, but a
Configure-Ack has not yet been received.
• Closed—Link is not available for traffic.
• Opened—Link is administratively available for traffic.
• Req-sent—An attempt has been made to configure the connection.
• State—(M120 and M320 routers) One of the following values:
• Ack-rcvd—A Configure-Request has been sent and a Configure-Ack has been received.
• Ack-sent—A Configure-Request and a Configure-Ack have both been sent, but a
Configure-Ack has not yet been received.
• Closed—Link is available (up), but no Open has occurred.
• Closing—A Terminate-Request has been sent but a Terminate-Ack has not yet been
received.
• Opened—Link is administratively available for traffic. A Configure-Ack has been both
sent and received.
• Req-sent—An attempt has been made to configure the connection. A Configure-Request
has been sent but a Configure-Ack has not yet been received.
• Starting—An administrative Open has been initiated, but the lower layer is still unavailable
(Down).
• Stopped—The system is waiting for a Down event after the This-Layer-Finished action,
or after sending a Terminate-Ack.
• Stopping—A Terminate-Request has been sent but a Terminate-Ack has not yet been
received.
• Last started—IPV6CP state start time.
• Last completed—IPV6CP state authentication completion time.
• Negotiated options:
• local interface identifier—Desired local address of the sender of a Configure-Request. If
all four octets are set to zero, the peer provides the IP address.
• remote interface identifier—IP address of the remote end of the link in dotted quad
notation.
• Negotiation mode—PPP Network Control Protocol (NCP) negotiation mode configured for
IPv6CP: Active or Passive
IPV6CP
Copyright © 2017, Juniper Networks, Inc.2904
ACX Series Universal Access Router Configuration Guide
