Juniper ACX2000 Configuration Guide

Table 219: Communities Output Field Values (continued)
DescriptionValue
Defines which VPN the route participates in; target has the format 32-bit IP address:16-bit
number. For example, 10.19.0.0:100.
target
Incoming IANA codes with a value between 0x1 and 0x7fff. This code of the BGP extended
community attribute is accepted, but it is not recognized.
unknown IANA
Incoming IANA codes with a value above 0x8000. This code of the BGP extended community
attribute is accepted, but it is not recognized.
unknown OSPF vendor
community
Sample Output
show route detail
user@host> show route detail
inet.0: 22 destinations, 23 routes (21 active, 0 holddown, 1 hidden)
10.10.0.0/16 (1 entry, 1 announced)
*Static Preference: 5
Next-hop reference count: 29
Next hop: 192.168.71.254 via fxp0.0, selected
State: <Active NoReadvrt Int Ext>
Local AS: 69
Age: 1:31:43
Task: RT
Announcement bits (2): 0-KRT 3-Resolve tree 2
AS path: I
10.31.1.0/30 (2 entries, 1 announced)
*Direct Preference: 0
Next hop type: Interface
Next-hop reference count: 2
Next hop: via so-0/3/0.0, selected
State: <Active Int>
Local AS: 69
Age: 1:30:17
Task: IF
Announcement bits (1): 3-Resolve tree 2
AS path: I
OSPF Preference: 10
Next-hop reference count: 1
Next hop: via so-0/3/0.0, selected
State: <Int>
Inactive reason: Route Preference
Local AS: 69
Age: 1:30:17 Metric: 1
ORR Generation-ID: 1
Area: 0.0.0.0
Task: OSPF
AS path: I
10.31.1.1/32 (1 entry, 1 announced)
*Local Preference: 0
Next hop type: Local
Next-hop reference count: 7
3011Copyright © 2017, Juniper Networks, Inc.
Chapter 42: Operational Commands
