Table 221: show route extensive Output Fields (continued)
Field DescriptionField Name
Name of the protocol that has added the route.Task
List of protocols that are consumers of the route. Using the following output as an example,
Announcement bits (3): 0-KRT 5-Resolve tree 2 8-BGP RT Background there are (3) announcement
bits to reflect the three clients (protocols) that have state for this route: Kernel (0-KRT), 5 (resolution
tree process 2), and 8 (BGP).
The notation n-Resolve inet indicates that the route is used for route resolution for next hops found
in the routing table. n is an index used by Juniper Networks customer support only.
Announcement bits
AS path through which the route was learned. The letters at the end of the AS path indicate the path
origin, providing an indication of the state of the route at the point at which the AS path originated:
• I—IGP.
• E—EGP.
• Recorded—The AS path is recorded by the sample process (sampled).
• ?—Incomplete; typically, the AS path was aggregated.
When AS path numbers are included in the route, the format is as follows:
• [ ]—Brackets enclose the local AS number associated with the AS path if more than one AS number
is configured on the routing device, or if AS path prepending is configured.
• { }—Braces enclose AS sets, which are groups of AS numbers in which the order does not matter.
A set commonly results from route aggregation. The numbers in each AS set are displayed in
ascending order.
• ( )—Parentheses enclose a confederation.
• ( [ ] )—Parentheses and brackets enclose a confederation set.
NOTE: In Junos OS Release 10.3 and later, the AS path field displays an unrecognized attribute and
associated hexadecimal value if BGP receives attribute 128 (attribute set) and you have not configured
an independent domain in any routing instance.
AS path
(BGP-learned routes) Validation status of the route:
• Invalid—Indicates that the prefix is found, but either the corresponding AS received from the EBGP
peer is not the AS that appears in the database, or the prefix length in the BGP update message is
longer than the maximum length permitted in the database.
• Unknown—Indicates that the prefix is not among the prefixes or prefix ranges in the database.
• Unverified—Indicates that origin validation is not enabled for the BGP peers.
• Valid—Indicates that the prefix and autonomous system pair are found in the database.
validation-state
Point-to-multipoint root address, multicast source address, and multicast group address when
multipoint LDP (M-LDP) inband signaling is configured.
FECs bound to route
(For route reflected output only) Originator ID attribute set by the route reflector.AS path: I <Originator>
Copyright © 2017, Juniper Networks, Inc.3030
ACX Series Universal Access Router Configuration Guide
