Table 221: show route extensive Output Fields (continued)
Field DescriptionField Name
Layer 2 VPN and VPLS network layer reachability information (NLRI).status vector
Local preference value included in the route.Localpref
BGP router ID as advertised by the neighbor in the open message.Router ID
In a routing table group, the name of the primary routing table in which the route resides.Primary Routing Table
In a routing table group, the name of one or more secondary tables in which the route resides.Secondary Tables
Name of the routing table whose active route was used to determine the forwarding next-hop entry
in the resolution database. For example, in the case of inet.0 resolving through inet.0 and inet.3, this
field indicates which routing table, inet.0 or inet.3, provided the best path for a particular prefix.
Originating RIB
Number of nodes in the path.Node path count
Number of forwarding next hops. The forwarding next hop is the network layer address of the directly
reachable neighboring system (if applicable) and the interface used to reach it.
Forwarding nexthops
Sample Output
show route extensive
user@host> show route extensive
inet.0: 22 destinations, 23 routes (21 active, 0 holddown, 1 hidden)
203.0.113.10/16 (1 entry, 1 announced)
TSI:
KRT in-kernel 203.0.113.10/16 -> {192.168.71.254}
*Static Preference: 5
Next-hop reference count: 29
Next hop: 192.168.71.254 via fxp0.0, selected
State: <Active NoReadvrt Int Ext>
Local AS: 64496
Age: 1:34:06
Task: RT
Announcement bits (2): 0-KRT 3-Resolve tree 2
AS path: I
203.0.113.30/30 (2 entries, 1 announced)
*Direct Preference: 0
Next hop type: Interface
Next-hop reference count: 2
Next hop: via so-0/3/0.0, selected
State: <Active Int>
Local AS: 64496
Age: 1:32:40
Task: IF
Announcement bits (1): 3-Resolve tree 2
AS path: I
OSPF Preference: 10
Next-hop reference count: 1
Next hop: via so-0/3/0.0, selected
Copyright © 2017, Juniper Networks, Inc.3032
ACX Series Universal Access Router Configuration Guide
