Table 127: show chassis fpc Output Fields (continued)
Level of OutputField DescriptionField Name
none specifiedTotal DRAM, in megabytes, available to the FPC's processor.Memory DRAM
(MB)
none specifiedPercentage of heap space (dynamic memory) being used by the FPC's processor.
If this number exceeds 80 percent, there may be a software problem (memory
leak).
NOTE: On MX Series routers and EX Series switches in a broadband edge
environment, heap utilization levels higher than 70 percent can affect unified
ISSU, router stability, or scaling capability.
Heap Utilization
(%)
none specifiedPercentage of buffer space being used by the FPC's processor for buffering
internal messages.
Buffer Utilization
(%)
detailAmount of DRAM available to the FPC's CPU.Total CPU DRAM
detailAmount of reduced latency dynamic random access memory (RLDRAM)
available to the FPC CPU.
Total RLDRAM
detailAmount of double data rate dynamic random access memory (DDR DRAM)
available to the FPC CPU.
Total DDR DRAM
detailAmount of static RAM (SRAM) used by the FPC's CPU.Total SRAM
detailTotal amount of memory used for storing packets and notifications.Total SDRAM
detailI/O Manager version number, manufacturer, and part number.I/O Manager ASICs
information
detailTime when the Routing Engine detected that the FPC was running.Start time
detailHow long the Routing Engine has been connected to the FPC and, therefore,
how long the FPC has been up and running.
Uptime
none specified(pic-status output only) Type of PIC.PIC type
all levelsGNF identifier associated with each line card.
(pic-status output only) GNF identifier associated with each PIC.
GNF (Node slicing)
Sample Output
show chassis fpc (EX6210 Switch)
user@switch> show chassis fpc
Temp CPU Utilization (%) Memory Utilization (%)
Slot State (C) Total Interrupt DRAM (MB) Heap Buffer
0 Empty
1 Online 7 5 0 1024 0 32
2 Empty
