Table 144: ATM show interfaces Output Fields (continued)
Level of OutputField DescriptionField Name
detail extensive none(ATM2) Virtual path identifier information:
• Flags—VPI flags can be one or more of the following:
• Active (virtual path is up)
• OAM (operation and maintenance is enabled)
• Shaping (shaping is configured)
• CBR, Peak
• OAM, Period—Interval at which OAM F4 loopback cells are sent.
• Up count—Number of F4 OAM cells required to consider the virtual path up;
the range is 1 through 255.
• Down count—Number of F4 OAM cells required to consider the virtual path
down; the range is 1 through 255.
• Total down time—Total number of seconds the VPI has been down since it
was opened, using the format Total down time: hh:mm:ss or Never.
• Last down—Time of last Down transition, using the formatLast down: hh:mm:ss
ago or Never.
• OAM F4 cell statistics—(Nonpromiscuous mode) OAM F4 statistics:
• Total received—Number of OAM F4 cells received.
• Total sent—Number of OAM F4 cells sent.
• Loopback received—Number of OAM F4 loopback cells received.
• Loopback sent—Number of OAM F4 loopback cells sent.
• Last received—Time at which the last OAM F4 cell was received.
• Last sent—Time at which the last OAM F4 cell was sent.
• RDI received—Number of OAM F4 cells received with the remote defect
indication bit set.
• RDI sent—Number of OAM F4 cells sent with the RDI bit set.
• AIS received—Number of OAM F4 cells received with the alarm indication
signal bit set.
• AIS sent—Number of OAM F4 cells sent with the AIS bit set.
Traffic statistics:
• Input bytes—Number of bytes received on the VPI.
• Output bytes—Number of bytes transmitted on the VPI.
• Input packets—Number of packets received on the VPI.
• Output packets—Number of packets transmitted on the VPI.
VPI
Logical Interface
All levelsName of the logical interface.Logical interface
detail extensive noneLogical interface index number, which reflects its initialization sequence.Index
detail extensive noneLogical interface SNMP interface index number.SNMP ifIndex
detail extensiveUnique number for use by Juniper Networks technical support only.Generation
