Table 145: T1 or E1 show interfaces Output Fields (continued)
Level of OutputField DescriptionField Name
detail extensive(Frame Relay) Statistics for traffic transiting the router. When a burst of traffic
is received, the value in the output packet rate field might briefly exceed the
peak cell rate. This counter normally stabilizes in less than 1 second.
Transit statistics
detail extensive noneProtocol family configured on the logical interface, such as iso, inet6, mlfr, or
mpls.
Protocol
detail extensive noneInterface name for the multilink bundle, if configured.Multilink bundle
detail extensive noneMTU size on the logical interface.MTU
detail extensiveUnique number for use by Juniper Networks technical support only.Generation
detail extensiveRouting table in which the logical interface address is located. For example, 0
refers to the routing table inet.0.
Route table
detail extensive noneInformation about the protocol family flags. Possible values are described in
the “Family Flags” section under Common Output Fields Description.
Flags
detail extensive noneInformation about the address flags. Possible values are described in the
Addresses Flags” section under Common Output Fields Description.
Addresses, Flags
detail extensive noneIP address of the remote side of the connection.Destination
detail extensive noneIP address of the logical interface.Local
detail extensive noneBroadcast address.Broadcast
detail extensive noneUnique number for use by Juniper Networks technical support only.Generation
detail extensive none(Frame Relay) DLCI number of the logical interface. The following DLCI
information is displayed: Flags, Total down time, Last down, and Traffic statistics
or (Input packets, Output packets). Flags can be one or more of the following:
Active—Set when the link is active and the DTE and DCE are exchanging
information.
Down—Set when the link is active, but no information is received from the
DCE.
DCE-Unconfigured—Set when the corresponding DLCI in the DCE is not
configured.
Configured—Set when the corresponding DLCI in the DCE is configured.
DCE-configured—Displayed when the command is issued from the DTE.
DLCI
detail extensive none(Frame Relay) Data-link connection identifier (DLCI) statistics.
Active DLCI—Number of active DLCIs.
Inactive DLCI—Number of inactive DLCIs.
DLCI statistics
2517Copyright © 2017, Juniper Networks, Inc.
