Table 194: show pfe tcam usage Output Fields
Field DescriptionField Name
Name of the application with TCAM resource usage errorsApp name
Name of the related applications for an application using the TCAM resource.Related-App-Name
Application priorityPrecedence
Status of the application. The status can be OK or FAILED.State
Describes the stage (egress, ingress, and pre-ingress)Tcam-stage
Logical representation of one or more tcam-slices.
NOTE: Tcam-slice represents the hardware TCAM block, where the TCAM
lookup can happen in parallel.
Group
Defines the matching capability of a given group. The following are the possible
values for Mode:
• SINGLE—TCAM space is single-wide. Single-wide modes is used to configure
a TCAM entry from a single TCAM slice.
• DOUBLE—TCAM space mode is double-wide. Double-wide mode is used to
configure two TCAM slices using one TCAM entry from each TCAM slice.
• DOUBLE(I)—TCAM space mode is double-wide intra-slice. Double-wide
intra-slice mode is used to configure a TCAM slice to use two TCAM entries
as a single entry.
Mode
TCAM resource used by an application to achieve the functionality of the
application.
Tcam-Entries
Counter resource used by an application.Counters
Policer resource used by an application.Policers
Available TCAM space.Free
Number of resources used by application or group.Used
Number of errors occurred due to shortage of TCAM resources.Errors
Shortage of TCAM resources for an applicationResource-Shortage
Number of TCAM resources allocated for a group.Allocated
Number of available TCAM resources for a group.Available
Number of TCAM slices used by the group.Hw grps used
Number of TCAM applications for a group.Tcam apps
Copyright © 2017, Juniper Networks, Inc.2878
ACX Series Universal Access Router Configuration Guide
