Table 214: show route advertising-protocol Output Fields (continued)
Level of OutputField DescriptionField Name
detail extensiveNumber, local preference, and path of the autonomous system (AS) that
originated the route. These values are stored in the Attrset attribute at the
originating router.
Attrset AS
detail extensiveLayer 2 encapsulation (for example, VPLS).Layer2-info:encaps
detail extensiveControl flags: none or Site Down.control flags
detail extensiveMaximum transmission unit (MTU) of the Layer 2 circuit.mtu
Sample Output
show route advertising-protocol bgp (Layer 3 VPN)
user@host> show route advertising-protocol bgp 10.255.14.171
VPN-A.inet.0: 6 destinations, 6 routes (6 active, 0 holddown, 0 hidden)
Prefix Nexthop MED Lclpref AS path
10.255.14.172/32 Self 1 100 I
VPN-B.inet.0: 6 destinations, 6 routes (6 active, 0 holddown, 0 hidden)
Prefix Nexthop MED Lclpref AS path
10.255.14.181/32 Self 2 100 I
show route advertising-protocol bgp detail
user@host> show route advertising-protocol bgp 111.222.1.3 detail
bgp20.inet.0: 4 destinations, 4 routes (4 active, 0 holddown, 0 hidden)
111.222.1.11/32 (1 entry, 1 announced)
BGP group pe-pe type Internal
Route Distinguisher: 111.255.14.11:69
Advertised Label: 100000
next hop: Self
Localpref: 100
AS path: 2 I
Communities: target:69:20
AIGP 210
111.8.0.0/16 (1 entry, 1 announced)
BGP group pe-pe type Internal
Route Distinguisher: 111.255.14.11:69
Advertised Label: 100000
Next hop: Self
Localpref: 100
AS path: 2 I
Communities: target:69:20
AIGP 210
show route advertising-protocol bgp detail (Labeled Unicast)
user@host>show route advertising bgp 1.1.1.3 detail
inet.0: 69 destinations, 70 routes (69 active, 0 holddown, 0 hidden)
* 1.1.1.8/32 (2 entries, 2 announced)
BGP group ibgp type Internal
Route Labels: 1000123(top) 1000124 1000125 1000126
Nexthop: 1.1.1.4
Copyright © 2017, Juniper Networks, Inc.2980
ACX Series Universal Access Router Configuration Guide
