Table 216: show route detail Output Fields (continued)
Field DescriptionField Name
Number of routes in the routing table and total number of routes in the following states:
• active (routes that are active)
• holddown (routes that are in the pending state before being declared inactive)
• hidden (routes that are not used because of a routing policy)
number routes
Route destination (for example:10.0.0.1/24). The entry value is the number of routes for this destination,
and the announced value is the number of routes being announced for this destination. Sometimes
the route destination is presented in another format, such as:
• MPLS-label (for example, 80001).
• interface-name (for example, ge-1/0/2).
• neighbor-address:control-word-status:encapsulation type:vc-id:source (Layer 2 circuit only; for example,
10.1.1.195:NoCtrlWord:1:1:Local/96).
• neighbor-address—Address of the neighbor.
• control-word-status—Whether the use of the control word has been negotiated for this virtual
circuit: NoCtrlWord or CtrlWord.
• encapsulation type—Type of encapsulation, represented by a number: (1) Frame Relay DLCI, (2)
ATM AAL5 VCC transport, (3) ATM transparent cell transport, (4) Ethernet, (5) VLAN Ethernet,
(6) HDLC, (7) PPP, (8) ATM VCC cell transport, (10) ATM VPC cell transport.
• vc-id—Virtual circuit identifier.
• source—Source of the advertisement: Local or Remote.
• source—Source of the advertisement: Local or Remote.
route-destination
(entry, announced)
(Next-to-the-last-hop routing device for MPLS only) Depth of the MPLS label stack, where the
label-popping operation is needed to remove one or more labels from the top of the stack. A pair of
routes is displayed, because the pop operation is performed only when the stack depth is two or more
labels.
• S=0 route indicates that a packet with an incoming label stack depth of 2 or more exits this routing
device with one fewer label (the label-popping operation is performed).
• If there is no S= information, the route is a normal MPLS route, which has a stack depth of 1 (the
label-popping operation is not performed).
label stacking
3001Copyright © 2017, Juniper Networks, Inc.
Chapter 42: Operational Commands
