Table 223: show route forwarding-table Output Fields (continued)
Level of OutputField DescriptionField Name
All levelsHow the route was placed into the forwarding table. When the detail keyword
is used, the route type might be abbreviated (as shown in parentheses):
• cloned (clon)—(TCP or multicast only) Cloned route.
• destination (dest)—Remote addresses directly reachable through an interface.
• destination down (iddn)—Destination route for which the interface is
unreachable.
• interface cloned (ifcl)—Cloned route for which the interface is unreachable.
• route down (ifdn)—Interface route for which the interface is unreachable.
• ignore (ignr)—Ignore this route.
• interface (intf)—Installed as a result of configuring an interface.
• permanent (perm)—Routes installed by the kernel when the routing table is
initialized.
• user—Routes installed by the routing protocol process or as a result of the
configuration.
Route Type (Type)
detail extensiveNumber of routes to reference.Route Reference
(RtRef)
extensiveRoute type flags:
• none—No flags are enabled.
• accounting—Route has accounting enabled.
• cached—Cache route.
• incoming-iface interface-number—Check against incoming interface.
• prefix load balance—Load balancing is enabled for this prefix.
• rt nh decoupled—Route has been decoupled from the next hop to the
destination.
• sent to PFE—Route has been sent to the Packet Forwarding Engine.
• static—Static route.
Flags
detail extensiveIP address of the next hop to the destination.Next hop
Copyright © 2017, Juniper Networks, Inc.3050
ACX Series Universal Access Router Configuration Guide
