Table 228: State Output Field Values (continued)
DescriptionValue
Route pending because of a hold-down configured on another
route.
Pending
Route scheduled for release.Release
Route from a higher-numbered routing table is available.RIB preference
64-bit prefix added to IP subnets to make them unique.Route Distinguisher
Route with a lower metric or MED is available.Route Metric or MED comparison
Route with lower preference value is available.Route Preference
Path through a neighbor with lower ID is available.Router ID
Route not a primary route.Secondary
Path is not usable because of one of the following conditions:
• The route is damped.
• The route is rejected by an import policy.
• The route is unresolved.
Unusable path
Last tiebreaker is the lowest IP address value.Update source
Table 219 on page 3010 describes the possible values for the Communities output field.
Table 229: Communities Output Field Values
DescriptionValue
4 bytes, encoding a 32-bit area number. For AS-external routes, the value is 0. A nonzero value
identifies the route as internal to the OSPF domain, and as within the identified area. Area
numbers are relative to a particular OSPF domain.
area-number
Link-bandwidth community value used for unequal-cost load balancing. When BGP has
several candidate paths available for multipath purposes, it does not perform unequal-cost
load balancing according to the link-bandwidth community unless all candidate paths have
this attribute.
bandwidth: local AS
number:link-bandwidth-number
Unique configurable number that identifies the OSPF domain.domain-id
Unique configurable number that further identifies the OSPF domain.domain-id-vendor
Link-bandwidth number: from 0 through 4,294,967,295 (bytes per second).link-bandwidth-number
Local AS number: from 1 through 65,535.local AS number
3125Copyright © 2017, Juniper Networks, Inc.
Chapter 42: Operational Commands
